LED Chameleon 90CRI Machine Lamp

SKU: ALEDMACH
2 Reviews
$149.00

This item is IN STOCK

Current Stock: 107

(*) Minimum Quantity: 1

ABOUT THIS PRODUCT:

Not Available for Canada, Pending CSA certification.

90 CRI Chameleon Color (Temperature) Control Full Brightness Control Casted Impact resistant head Shadow Diffusing Lens 5 Joint Design 50,000 hour service life (5.7 Years) 100-240V LED Driver, 110V plug included Low Heat & Energy Consumption Dust & Water Resistant.


FEATURES:

90 CRI
Chameleon Color (Temperature) Control
Full Brightness Control
Casted Impact resistant head
Shadow Diffusing Lens
5 Joint Design
50,000-hour service life (5.7 Years)
100-240V LED Driver, 110V plug included
Low Heat & Energy Consumption
Dust & Water Resistant
14/12 Bandsaw - Saw is pre-drilled with 2 mounting locations - No bracket required

  • 14BX Bandsaw - Saw is pre-drilled with 2 mounting locations - No bracket required
  • 18BX Bandsaw - Saw is pre-drilled with 2 mounting locations - No bracket required
  • 18CX Bandsaw - Saw is pre-drilled with 2 mounting locations - No bracket required
  • Revo 12/16 Lathe - Lathe is now supplied with bracket - Older models may or may not have bracket.
  • Revo 15/24 Lathe - Lathe is supplied with mounting bracket.
  • Revo 18/36 Lathes - Lathe is supplied with dual mounting brackets.
  • Revo 24/36 Lathe - Lathe is supplied with dual mounting brackets.
  • JX/12 ShearTec2 Jointer - Jointer is supplied with mounting bracket.

    Detailed Specs:
    Bulb Wattage: 14 Watt
    Bulb Angle: 60
    Electrical: 100-240V/1PH/60HZ
    Consumable Spec:: BULB: 14W LED
    Illuminance*: 0-940
    Temperature: 3000K-6000K
    Color Rendering Index (CRI): 90 CRI
    * Measurement taken at full brightness from 1 meter from light source. For reference, an iphone X LED light was measured at 49.8 lumens:
    Service Life: 50000
    Controls: Illuminance, Temperature, Power
    Electrical:
    110 or 220 volt with built-in driver.
    Pre-wired for 110 volt
    Plug change required for 220 volt - See video below (220 plug not included)

    Materials:
    Lens: Diffused Glass
    Head: Casted Alloy
    Arm: Aluminum
    Base: Casted Alloy

    Dimensions:
    Maximum Reach: 37"
    Left or Right Range: 32"
    Head Dimensions: 5"x5"
    Assembled dimensions: W5 x L22 x H6 inch
    Base Tapping: 60mm x 60mm x 60mm x 60mm

Details

Details

80, 90, 95 CRI are color rendering indexes. This index is used to compare artificial light sources to that of natural light that we perceive through our eyes on a sunny clear day. The higher the CRI, the more real things will look when shined upon. The out new Chameleon LED lights with 90 CRI (ALEDMACH) and 95 CRI (ALEDLATHE) for the best possible lighting. With the Led benefits of long life, low power consumption, and low heat emission; this makes the Laguna LED line the best machine lamp available. Chameleon Color (Temperature) Control allows the user to tune the environment with the best lighting possible. Poor lighting in a workspace can distort colors, reflect poorly, and cause shadows that make the details fade. The Chameleon Color control is technology taken down from surgeons and doctors that we thought would be very useful for the makers. Full Brightness Control works in unison with the Chameleon color control allowing the user to further tune the lighting environment.


 Casted Impact-resistant heads. The heads are water and dust resistant and can withstand a punch well enough for military standards.

Shadow Diffusing Lens makes the shadows less crisp and noticeable. An undiffused light will cast a shadow with crisp lines, adding distractions. The diffusing lenses give more natural and pleasing light.


Multiple Joint Design. Solid joints are used to allow the user to move the light wherever it needs to be. These joints can easily be tightened and loosened as desired and are prepped with Loctite prior to shipping.

 50,000-hour service life (5.7 Years). This means you can turn the light on, and leave it on, for 5.7 years before the bulb dies. This is because LED technology is very efficient, will not get hot, and uses very little electricity to operate. 100-240V LED Driver, 110V plug included. Another crucial component to the longevity of the light is the driver. Our drivers allow for a voltage input anywhere from 100V to 240V and are equipped standard with a 110V 5-15 plug. This means that if you need 208V or 220V you can simply cut the plug and rewire it to the receptacle.

 Low Heat & Energy Consumption. Based on recent electricity data, the 14W Chameleon lights will only cost $2.56 a year if used for 5 hours every day. Compare this to a typical Halogen Machine light, the cost is up to ten times that, and that is not included replacement bulbs or possible fire hazards.
